2 HP 6 Paddle Wheel Aerator

About 2 HP 6 Paddle Wheel Aerator

Technical Specifications

- Oxygen Transfer Rate: 4.5 kg/h

- Power Consumption: 2.8 Amps

- Input Power: 440 volts, 50 Hz

- Motor: 4 pole, 1440 R.P.M

- Gear Box: 1:12 reducer (120 R.P.M)

- Material: Made with 100% virgin materials

- Manufacturing: All components are made in India

- Warranty: 1-year replacement warranty on all parts (excluding motor)

Key Benefits of the 2 HP 6-Paddle Wheel Aerator

- Enhanced Oxygen Levels: The 2 HP motor and 6-paddle design significantly increase oxygenation, improving pond conditions.

- Improved Water Quality: Helps prevent water stagnation, supporting a cleaner and healthier environment for aquatic life.

- User-Friendly: Designed for easy installation and operation, making it ideal for large aquaculture ponds.

Product Details

| Component     | Material       | Quantity |

|-------------------|----------------------|----------|

| Floats      | HDPE         | 4    |

| Motor Cover    | HDPE         | 1    |

| Motor       |2 HP         | 1    |

| Gear Box     | Bevel Gear      | 1    |

| Impellers     | PPCP         | 6    |

| Frame       | SS 304/FRP      | 1    |

| Shaft Couplings  | Cast Iron      | 2    |

| Nuts & Bolts   | SS 304        | 1 set  |

| Shaft       | SS 304        | 2    |

| Shaft Supporter  | Nylon        | 4    |

Invest in the 2 HP 6-Paddle Wheel Aerator to optimize oxygenation, improve water quality, and promote a healthier aquatic ecosystem.
